Standard Interconnection Materials & Equipment (General)

Name: Standard Interconnection Materials & Equipment (General)
Availability: InStock

[SIMGEN] Standard Interconnection Materials & Equipment (General)
Equipment & Materials for Solar System Installation

Service Description:
This package includes all necessary components and interconnection materials for a proper and fully operational solar energy system.

Included Equipment & Materials
1. AC-Interconnection Box – Provides a safe and compliant connection between the solar system and the electrical grid.
2. Battery Combiner & DC Switch – Combines multiple battery units into a single hub and connects them to the inverter.
3. PV Combiner/SPD (Surge Protection Device) – Protects the system from electrical surges.
4. Interconnection Materials – Includes necessary connectors, breakers, fuses, and accessories.
5. Grounding Pin & Accessories – Ensures proper earthing for system safety.
6 Cable Ducts – Protective conduits to organize and safeguard electrical wiring.
7. AC & DC Cables – High-quality electrical cabling for power transmission (up to 14 meters 5*6mm2 AC Interconnection cable).

Cable Limitation & Additional Charges
1. Cable Distance Beyond 14 Meters – Any additional cabling beyond 14 meters will be charged separately and discussed in advance.
2. Additional Equipment Requirements – Any extra components beyond the standard package will be billed separately with prior client approval.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

This Package includes:

30 Meters Kabel YMVK 5x10 mm

10 Meters AWG 4 Red

10 Meters AWG 4 Black

2 Meters AWG 8 Red

2 Meters AWG 8 Black

4 Units Cable Size Reducer

50 Meters VDS Ground Cable (yellow/green 10mm)

4 Meters VDS black 10mm

2 Meters VDS blue 10mm

30 Meters BCN (10mm)

10 Units Ty-raps small

10 Units Ty-raps medium

7 Meters Cable Duct 90x50 (2M)

4 Units Ducting Connectors 90° Curve

4 Units Ducting Connectors T Curve

1 Unit Ducting Connectors end close

5 Meters Cable Duct 60x50 (2M)

3 Units Ducting Connectors 90° Curve

1 Unit Ducting Connectors T Curve

1 Unit Ducting Connectors end close

24 Meters Flexible Conduit (sun protected) (2")

8 Units Flexible Conduit T Connectors (2")

1 Unit Grounding Pin (1.5M)

1 Unit Ground Pin Grip

1 Unit I-Box

1 Unit Grounding Strip Bus

1 Unit 4 phase Switch 40Amps
